Overview
This is a logic gate workbook used to design and visualize logic circuits. The different states can be animated and the update rate can be adjusted. A vector SVG file can be exported to be viewed in a web page or edited in any standard SVG editor. Several examples of the most common circuits are included as a library.
Features
Visual feedback of logic flowLibrary examples of common circuitsColors can be customizedSVG export to display in any web page or SVG editor
Additional Information
