Overview
3DPlay is an application of Dassault Systèmes 3DEXPERIENCE Platform, which allows you to instinctively visualize and experiment 3D objects.
Multi-touch gestures let you pan, zoom, rotate 3D objects easily. 3DPlay also provides original and fun Experiences like the explode of the sub-parts of an assembly with ‘Matrix Effect’.
3DPlay provides also integrated collaboration services in order to connect people inside and outside the enterprise, within a single visual and intuitive 3D environment.
Features:
* Experiment 3D Content (3DXML) coming from any source: email attachments, cloud storage services, 3D content web sites
* Support for 3DXML and STEP AP242 Tessellated files as well as major CAD systems
* Intuitive and easy-to-use user interface
* Zoom, pan and rotate your 3D Objects within an instinctive multi-touch environment
* Integrated tool allowing to grab the screen and to share the generated image by email, save to Photo Gallery
* Create freehand 3D annotations
* Cut elements with one finger, measure dimensions, hide of show 3D parts
* Ability to view Product and Manufacturing Information (PMI) and Functional Tolerancing and Annotation (FT&A)
NOTE : 3DPlay needs to be activated either by using your DS Passport (email/login and password) or by creating your own account. It takes no more than a few seconds to access all DS online services and it is totally FREE. 3DPlay will guide you thru this activation process.
DS Passport is also available on the Web at :
https://eu1-ds-iam.3dexperience.3ds.com/
What's new
* Version compatible with the upcoming 3DEXPERIENCE Platform R2021x FD06 by Dassault Systèmes
* Enhanced loading times of models, especially from the 3DSpace offer by Dassault Systèmes
* Improved Fly Walk feature
* Supported formats from Dassault Systèmes\' 3DDrive repository have been enriched
* Support for "Functional Tolerance and Annotations" data has been enriched to CATPart and STEP files from Dassault Systèmes\' 3DDrive repository
* 3DPlay now benefits from the sharing capabilities to Dassault Systèmes\' 3DSwym communities, now directly accessible from the Action Bar
* Improved on-boarding experience
* Performances enhancements
Additional Information
- Developed by Dassault Systèmes
- Version 2022.07.25
-
Requires
Available on: PC, Mobile, Surface Hub
OS: Windows 10 version 14316.0 or higher
- Published 2016-02-26
- Size 217.39 MB
- File Type appx/msix
-
Language
English (United States)
-
Permissions
Uses all system resources
Use your location
Use your webcam
Use your microphone
Use your contacts
Access your Internet connection
Access your home or work networks
Programmatically access your 3D Objects
Access to your Account’s username and picture
- Microsoft Store ID 9wzdncrdjzv3
